DG-400L-7
iSG Taiwan 4U industrial rackmount chassis D Storm DG-400L-7

Product Introduction
iSG Taiwan 4U industrial rackmount chassis D Storm DG-400L-7. It supports up to seven add-on cards and total storage capacity up to 5 storage drives for RAID configuration. DG-400L-7 provide your server or cluster maximum reliability and performance. The Rugged DG Series rackmount chassis are designed to withstand the toughest and compact environment and perform industrial applications that require spill proof with 27in depth. The DG-400L-7 is high performance rackmount chassis with a spill proof key-locked bezel, shock absorbing drive cage, and designed with 7x 5.25 bay, 1x 3.5 external Bay, 1x 3.5 internal bay. The IPC DG series is the most versatile and tough rackmount chassis for critical application.


Model NumberDG-400L-7
RoHS Compliance VersionYes
Standard Drive Bays 3.5" Drives: 1
3.5" Drive (internal): 1
5.25" Drives: 7
IndicatorsPower, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 )
SwitchesPower, Reset
Supported PSU TypePS2, Mini Redundant
Expansion Slots7
SecurityFront Bezel Key Lock
Material of Front BezelSECC Zinc-Coated Steel
Material of HandleSECC Zinc-Coated Steel
Material of Main Chassis1.2mm SECC Zinc-Coated Steel (Japan Made)
Color of Front BezelBlack
Color of Main ChassisBlack
Air FilterGrill net
Motherboard Size12 x 13 (EATX, ATX, microATX)
Cooling Fan1x80mm, 3x120mm
Optional Fan:80mm x1
Dimensions (WxHxD)19.00" x 7.00" x 27.90"
482.6 mm x 177.8 mm x 708.7 mm
